1.77 inch TFT LCD Display 128x160 SPI ST7735 14PIN

Nama merek:	Genyu
MOQ:	1000
harga:	$0.99-1.25

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Guangdong, Cina

ukuran tampilan:

1,77 inci

Resolusi:

128x160 piksel

Sudut pandang:

jam 12

Drive IC:

ST7735V3

Ukuran modul:

33.3x42.9x2.2 mm

Area aktif:

28.03x35.04 mm

Jenis lampu latar:

2 LED

Arus Lampu Latar:

40mA

Tipe antarmuka:

4SPI

Pin FPC:

14pin

Jenis tampilan:

TN, Transmisif

Suhu operasi:

-20 ℃ ~+70 ℃

Suhu penyimpanan:

-30 ℃ ~ + 80 ℃

Metode koneksi:

14 Pin

Ukuran LCD:

33.3x42.9x2.2 mm

Menyoroti:

1.77 inch TFT LCD display

128x160 SPI ST7735 display

14PIN TFT LCD panel

Deskripsi Produk

Genyu 1.77 inch TFT LCD Display 128x160 Pixels TN 12 O'clock ST7735 14PIN with SPI Interface

Product Specifications

Attribute	Value
Type	TFT
Display Size	1.77 inch
Supplier Type	Manufacturer
Resolution	128x160 dots
Viewing Angle	12 O'clock
Drive IC	ST7735V3
Module Size	33.3(H)x42.9(V)x2.2(T) mm
Active Area	28.03(H)x35.04(V) mm
Backlight	2 LED, 40mA
Interface	4SPI
FPC number	14pin

Key Features

Model Number: GY-TFT018F089
Display Type: TN, Transmissive
Operating Temperature: -20℃~+70℃
Storage Temperature: -30℃~+80℃
Connection method: 14 PIN

Packaging & Shipping

Payment: T/T, Western Union, Paypal. Please contact us before payment.

Delivery: Items shipped within 3 working days after payment received.

DHL/UPS/FedEx/TNT: 2-5 working days
EMS: 7-10 working days
CPAM/HKPAM: 10-30 working days

Packaging:

Anti-static bag or Bubble bag (for samples)
Plastic pallet
Carton box

Similar Products

Product Customization

Genyu specializes in small to medium size LCD display modules including:

Custom Segment Displays
Monochrome Graphic Displays
OLED Display Modules
Color TFT Displays

Segment & Graphic displays can be fully customized with tooling cost for development and MOQ for bulk orders.

OLED & TFT displays have standard sizes but we can customize FPC/Interface/Touch Screen/Backlight based on requirements.

Our Services

Detailed product instructions and technical support provided
All products undergo aging tests with 100% visual and electric inspection
Product upgrade notifications with backward compatibility
12-month warranty period

Frequently Asked Questions

Q: Are you a manufactory or trade company?

A: We are a factory located in Shenzhen and Jiangxi, specializing in TN, HTN, STN, FSTN, VA monochrome LCD, Micro OLED Screen, Color TFT Display Panels, LED Backlights, and LCD Modules.

Q: Will you offer a free sample?

A: For first cooperation, samples are charged with amount returned at mass order stage. Regular cooperation may qualify for free samples.

Q: What is the delivery time?

A: Sample orders: 2-3 weeks. Mass production: 4-6 weeks.

Q: Can you customize the LCD or touch screen?

A: Yes, we can customize backlight brightness, FPC cable, and complete touch panels including color, shape, and cover thickness.

Q: Which applications are your products mainly used for?

A: Embedded systems, Intercom systems, Biometrics, HMI, Smart home, Robotics, Hand-held PDAs, Aftermarket automotive, etc.
